Kubernetes Guide: Part 8

Understanding Kubernetes Services: A Comprehensive Guide

A Kubernetes Service is an object that helps you expose an application running in one or more Pods in your cluster. Since pod IP addresses can change when pods are created or destroyed, a service provides a stable IP that doesn't change. This ensures that both internal and external users can always connect to the right application, even if the pods behind it are constantly changing. By default the service that is created is clusterIP, it is useful for communication within the cluster.

To create a service (default: ClusterIP)

  kubectl expose <deployment/pod-name> --port=80

To see the services
```
  kubectl get svc -owide
```

What Are Endpoints in Kubernetes?

Endpoints are objects that list the IP addresses and ports of the pods associated with a specific service. When you create a service in Kubernetes, it uses a selector to determine which pods it should communicate with. The Endpoints object automatically updates as pods are added or removed, ensuring that the service always knows where to send traffic. It play a crucial role in connecting services to the pods they manage.

Viewing Endpoints
kubectl get endpoints <service-name>

Exploring Different Types of Kubernetes Services

ClusterIP
NodePort
LoadBalancer
ExternalName
Headless
ExternalDNS

Networking Fundamentals in Kubernetes: A Deep Dive

Inside each node, there's always a veth(Virtual Ethernet) pair for networking. When a pod runs, a special container called the pause container is also created. For example, if you create a pod with two containers, like busybox and nginx, there will actually be three containers: the two you defined and the pause container. The pod gets its own IP, and this IP is connected to an interface called eth0(Ethernet interface) inside the pod using CNI.

Create a multi-container pod (mcp.yml)

  apiVersion: v1
  kind: Pod
  metadata:
    name: shared-namespace
  spec:
    containers:
      - name: p1
        image: busybox
        command: ['/bin/sh', '-c', 'sleep 10000']
      - name: p2
        image: nginx

  kubectl apply -f mcp.yml

To see the pod’s IP

  kubectl get pod shared-namespace -owide

Check the node where the pod is running and SSH into it
```
  ssh node01
```
To view the network namespaces created
```
  ip netns list
```
To find the pause container
```
  lsns | grep nginx
```
Get details of the pause container's namespaces (net, ipc, uts)
```
  lsns -p <PID-from-the-previous-command>
```
To check the list of all network namespaces
```
  ls -lt /var/run/netns
```

Exec into the namespace or into the pod to see the ip link

  ip netns exec <namespace> ip link
  kubectl exec -it <pod-name> -- ip addr

Find the veth Pair
- Once you run the above command, you may see an interface with a name like eth@9. The number after @ represents the identifier of the virtual Ethernet (veth) pair interface.
- To find the corresponding link on the Kubernetes node, you can search using this identifier. For example, if the number is 9, run the following on the node

    ip link | grep -A1 ^9

This will show the details of the veth pair on the node

Inter Node communication

Here, Traffic(packet) goes to eth0 and then veth1 acts as tunnel and traffic goes to root namespace and bridge resolve the destination address using the ARP table then Veth1 send traffic(packet) to pod B. This all only happens if there is a single node

StatefulSet: Managing Stateful Applications in Kubernetes

It helps manage stateful applications where each pod needs a unique identity and keeps its own data. It makes sure pods are started, updated, and stopped one by one, in a set order. Each pod has a fixed name and can keep its data even if it is restarted or moved to another machine. This is useful for apps like databases, where data and order matter.

Key Differences Between Deployments and StatefulSets

Feature	Deployment	StatefulSet
Use Case	For stateless applications	For stateful applications
Pod Identity	Pods are interchangeable and do not have stable identities	Pods have unique, stable identities (e.g., `pod-0`, `pod-1`)
Storage	Typically uses ephemeral storage, data is lost when a pod is deleted	Each pod can have its own persistent volume attached
Scaling Behavior	Pods are scaled simultaneously and in random order	Pods are scaled sequentially (e.g., `pod-0` before `pod-1`)
Pod Updates	All pods can be updated concurrently	Pods are updated sequentially, ensuring one pod is ready before moving to the next
Order of Pod Creation/Deletion	No specific order in pod creation or deletion	Pods are created/deleted in a specific order (e.g., `pod-0`, `pod-1`)
Network Identity	Uses a ClusterIP service, no stable network identity	Typically uses a headless service, giving each pod a stable network identity
Examples	Microservices, stateless web apps	Databases (MySQL, Cassandra), distributed systems requiring unique identity or stable storage
Use of Persistent Volumes	Persistent volumes are shared across pods (if needed)	Each pod gets a dedicated persistent volume

The Service that is created in StatefulSet is the ClusterIP: none i.e., (headless service)

StatefulSet example for deploying a MySQL database in Kubernetes

  apiVersion: apps/v1
  kind: StatefulSet
  metadata:
    name: mysql
  spec:
    serviceName: "mysql-service"
    replicas: 3
    selector:
      matchLabels:
        app: mysql
    template:
      metadata:
        labels:
          app: mysql
      spec:
        containers:
        - name: mysql
          image: mysql:5.7
          ports:
          - containerPort: 3306
            name: mysql
          volumeMounts:
          - name: mysql-storage
            mountPath: /var/lib/mysql
    volumeClaimTemplates:
    - metadata:
        name: mysql-storage
      spec:
        accessModes: ["ReadWriteOnce"]
        resources:
          requests:
            storage: 1Gi

Each pod will have its own persistent storage (mysql-storage).
Pods will have stable network names (mysql-0, mysql-1, etc.), and their data will persist even if they restart.

Create a StatefulSet

  cat <<EOF | kubectl apply -f -
  apiVersion: apps/v1
  kind: StatefulSet
  metadata:
  name: postgres
  spec:
  serviceName: "postgres"
  replicas: 3
  selector:
  matchLabels:
  app: postgres
  template:
  metadata:
  labels:
  app: postgres
  spec:
  containers:
  - name: postgres
  image: postgres:13
  ports:
  - containerPort: 5432
  name: postgres
  env:
  - name: POSTGRES_PASSWORD
  value: "example"
  volumeMounts:
  - name: postgres-storage
  mountPath: /var/lib/postgresql/data
  volumeClaimTemplates:
  - metadata:
  name: postgres-storage
  spec:
  accessModes: [ "ReadWriteOnce" ]
  resources:
  requests:
  storage: 1Gi
  EOF

A persistent volume and persistent volume claim is also created
```
  kubectl get pv
```
```
  kubectl get pvc
```
Check for pods that is created

Create a service (svc.yml)

  apiVersion: v1
  kind: Service
  metadata:
    name: postgres
    labels:
      app: postgres
  spec:
    ports:
    - port: 5432
      name: postgres
    clusterIP: None
    selector:
      app: postgres

Increase the replicas and you will see the each pod have a ordered and fixed name
```
  kubectl scale statefulset postgres --replicas=6
```
```
  kubectl get pod
```
If you delete a pod a new pod with the same name again created
```
  kubectl delete pod postgres-3
```

Check if the service is working or not

  kubectl exec -it postgres-0 -- psql -U postgres

NodePort: Exposing Your Kubernetes Application

A NodePort is a way to let people from outside the cluster access your app. It opens a specific port on every node in the cluster, allowing you to reach the app using the node's IP and the assigned port. This port is a number in the range 30000–32767. You can access your application by visiting <NodeIP>:<NodePort>, where NodeIP is the IP address of any node in the cluster, and NodePort is the port assigned by Kubernetes.

Where it's useful ?

For testing and development: You can quickly share access to apps without need of extra networking setup.
For small or internal projects: If a company doesn't use cloud-based load balancers or advanced setups, NodePort is a simple solution to expose an app.

YAML configuration for a NodePort service that exposes an nginx deployment or pod

apiVersion: v1
kind: Service
metadata:
  name: nginx-nodeport
  labels:
    app: nginx
spec:
  type: NodePort  # Specify the service type as NodePort
  selector:
    app: nginx  # This must match the labels of the nginx pods
  ports:
    - protocol: TCP
      port: 80  # The port the service will listen on
      targetPort: 80  # The port the nginx container is listening on
      nodePort: 30008  # NodePort exposed (optional, Kubernetes can assign one if omitted)

Create a Pod and expose it using NodePort service

kubectl run nginx --image=nginx
kubectl expose pod nginx --type=NodePort --port 80

Access the Server http://192.168.1.4:32613

Check NodePort and KUBE Rules

to check the rules in the iptables firewall configuration related to Kubernetes NodePort services
```
  sudo iptables -t nat -L -n -v | grep -e NodePort -e KUBE
```
Check Specific NodePort Rules
```
  sudo iptables -t nat -L -n -v | grep 32613
```
This indicates that traffic coming to port 32613 (your NodePort) is being redirected properly to the appropriate service.

LoadBalancer: Making Your Application Public

It allows your application to be accessible to the public over the internet. When you create a service of this type, Kubernetes asks your cloud provider (like AWS, GCP, or Azure) to set up a load balancer automatically.

This service type is ideal when you want to expose an application, such as a web server, to users outside your cluster. The cloud provider provides an external IP address, which users can use to access your application.

The load balancer automatically distributes incoming traffic to all the pods running the service. This helps spread the traffic evenly and avoid overloading any single pod.

LoadBalancer YAML file
apiVersion: v1
kind: Service
metadata:
  name: nginx-loadbalancer
spec:
  type: LoadBalancer  # This makes it a LoadBalancer service
  selector:
    app: nginx  # This selects the nginx pods
  ports:
    - protocol: TCP
      port: 80         # Exposes port 80 (HTTP) to the public
      targetPort: 80   # The port on the nginx container
How It Works:

You create the LoadBalancer service.

Kubernetes communicates with the cloud provider, and a load balancer is created.

The load balancer assigns an external IP address.

Traffic from the external IP is sent to your service, which distributes it to the nginx pods.

Creating a LoadBalancer service in minikube

  kubectl run nginx --image=nginx
  kubectl expose pod nginx --type=LoadBalancer --port=80

Creates a network tunnel, making your LoadBalancer service accessible
```
  minikube tunnel
```
Access the Service at External-ip

Why Avoid LoadBalancer in Production?

Cost: LoadBalancers can be expensive, as cloud providers charge for them.
Scalability Problems: They might struggle with sudden increases in traffic.
Single Point of Failure: If the LoadBalancer fails, all services using it can go down.
Limited Flexibility: They have fixed rules, making it hard to manage complex traffic needs.
Performance Delays: They can add extra time (latency) to how quickly users access your services.
Dependence on Cloud Services: If the cloud provider has issues, your services might become unavailable.
Complex Setup: Managing LoadBalancers can complicate your system, especially with multiple clusters.

Alternatives to LoadBalancer for Kubernetes

Ingress Controllers: These are cheaper and allow more flexible traffic management.
Service Mesh: They help manage traffic and improve observability without needing a LoadBalancer.

ExternalName: Mapping Services to External DNS Names

The ExternalName service type is a special kind of service in Kubernetes that allows you to map a service to an external DNS name. Instead of using a cluster IP, it returns a CNAME record with the specified external name. We use it when we need to communicate to an external service (like external API or database) without changing your application code. Using this we can also communicate with services that is present in other namespaces.

Example: Two services within two other namespaces communicate with each other

Use This file to get the Sourcecode

Create two namespace

  kubectl create ns database-ns
  kubectl create ns application-ns

Create the database pod and service

  kubectl apply -f db.yaml
  kubectl apply -f db_svc.yaml

Create ExternalName service

  kubectl apply -f externam-db_svc.yaml

Create Application to access the service Docker build

  docker build --no-cache --platform=linux/amd64 -t ttl.sh/saiyamdemo:1h .

Create the pod
```
  kubectl apply -f apppod.yaml
```
Check the pod logs to see if the connection was successful
```
  kubectl logs my-application -n application-ns
```

Ingress: Controlling User Access to Kubernetes Applications

It is a way to control how users access your applications running in Kubernetes. Think of it as a gatekeeper that directs traffic to the right place. To use ingress we firstly need to deploy an Ingress Controller on the cluster and the Ingress are implemented through Ingress Controller. Ingress controllers are the open source project of many companies such as NGINX, Traefik, Istio Ingress, etc.

Now, we create a service using ClusterIP and a resource using Ingress. User request firstly goes to ingress controller then ingress controller send it to ingress then after it goes to the clusterIP service configured by us and at last it goes to the pod. Here we deploy Ingress Controller as the LoadBalancer.

Why Use Ingress?

Single Address: Instead of having different addresses for each app, you can use one address for everything.
Routing by URL: You can send users to different apps based on the URL they visit. For example, /app1 goes to one app and /app2 goes to another.
Secure Connections: Ingress can handle secure connections (HTTPS) easily, so your apps are safe to use.
Balancing Traffic: It spreads out incoming traffic evenly, so no single app gets overloaded.

Example

Imagine you have two apps:

A website
An API

You can set up Ingress to route traffic like this:

If someone goes to /, they get the website.
If they go to /api, they get the API.

Here’s how you might set it up:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: example-ingress
spec:
  rules:
  - host: "my-app.com"
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: website-service
            port:
              number: 80
      - path: /api
        pathType: Prefix
        backend:
          service:
            name: api-service
            port:
              number: 80

Create a deployment (deploy.yaml)

  apiVersion: apps/v1
  kind: Deployment
  metadata:
     name: nginx-deployment
  spec:
     replicas: 1
     selector:
     matchLabels:
        app: nginx
     template:
        metadata:
           labels:
             app: nginx
        spec:
           containers:
           - name: nginx
             image: nginx:latest
             ports:
             - containerPort: 80
             volumeMounts:
             - name: config-volume
               mountPath: /etc/nginx/nginx.conf
               subPath: nginx.conf  # Ensure this matches the filename in the ConfigMap
             volumes:
             - name: config-volume
               configMap:
               name: nginx-config

  kubectl apply -f deploy.yaml

Create a clusterIP service (svc.yaml)

  apiVersion: v1
  kind: Service
  metadata:
     name: nginx-service
  spec:
     selector:
        app: nginx
      ports:
      - protocol: TCP
        port: 80
        targetPort: 80

  kubectl apply -f svc.yaml

verify the service is created
```
  kubectl get svc
```

Create a nginx.conf file

  user  nginx;
  worker_processes  auto;

  error_log  /var/log/nginx/error.log notice;
  pid        /var/run/nginx.pid;

  events {
  worker_connections  1024;
  }

  http {
  include       /etc/nginx/mime.types;
  default_type  application/octet-stream;

  log_format  main  '$remote_addr - $remote_user [$time_local] "$request" '
  '$status $body_bytes_sent "$http_referer" '
  '"$http_user_agent" "$http_x_forwarded_for"';

  access_log  /var/log/nginx/access.log  main;

  sendfile        on;
  #tcp_nopush     on;

  keepalive_timeout  65;

  #gzip  on;

  server {
  listen       80;
  server_name  localhost;

  location / {
  root   /usr/share/nginx/html;
  index  index.html index.htm;
  }

  location /public {
  return 200 'Access to public granted!';
  }

  error_page   500 502 503 504  /50x.html;
  location = /50x.html {
  root   /usr/share/nginx/html;
  }
  }
  }

Create a ConfigMap

  kubectl create configmap nginx-config --from-file=nginx.conf

Access the server
```
  curl <cluster-IP>
```

Now we need to access this application from outside the cluster without using NodePort and LoadBalancer service

Install Ingress controller first

  kubectl apply -f https://raw.githubusercontent.com/kubernetes/ingress-nginx/controller-v1.9.4/deploy/static/provider/cloud/deploy.yaml

Create a Ingress object (ingress.yaml)

  apiVersion: networking.k8s.io/v1
  kind: Ingress
  metadata:
    name: bootcamp
  spec:
    ingressClassName: nginx
    rules:
    - host: "kubernetes.hindi.bootcamp"
      http:
        paths:
        - path: /
          pathType: Prefix
          backend:
            service:
              name: nginx-service
              port:
                number: 80
        - path: /public
          pathType: Prefix
          backend:
            service:
              name: nginx-service
              port:
                number: 80

ssh onto the node where the pod is deployed and the change the /etc/hosts file

  # add this in file
  <node-internal-IP> <nodeName>
  <node-internal-IP> kubernets.hindi.bootcamp

Now apply the create ingress.yaml file
```
  kubectl apply -f ingress.yaml
```
We need to connect user to the ingress controller
```
  curl kubernetes.hindi.bootcamp:30418
```

ExternalDNS: Connecting Kubernetes to DNS Providers

ExternalDNS is a Kubernetes-native solution that automatically manages DNS records for services and ingress resources within Kubernetes clusters. It simplifies the process of associating a Kubernetes service with a domain name, ensuring that services deployed in Kubernetes are easily accessible from outside the cluster via friendly domain names rather than IP addresses.

How ExternalDNS Works

ExternalDNS continuously monitors Kubernetes resources such as Service and Ingress objects. It then communicates with a DNS provider to ensure that the corresponding DNS records reflect the current state of the Kubernetes cluster. The typical workflow is as follows:

Service or Ingress Resource Created: When a new service or ingress resource is deployed in Kubernetes, it usually exposes an external IP or hostname.
DNS Record Creation: ExternalDNS detects the new service and automatically creates the corresponding DNS record in the external DNS provider (e.g., AWS Route 53).
Dynamic Updates: If the service’s external IP changes (e.g., due to a rolling update or scaling event), ExternalDNS updates the DNS record accordingly.
Resource Deletion: When a service or ingress resource is removed, ExternalDNS also deletes the associated DNS records.

Use Cases for ExternalDNS

Public Service Exposure: ExternalDNS is ideal for exposing services running inside Kubernetes clusters to the public via user-friendly domain names.
Multi-Cloud Deployments: In multi-cloud environments, ExternalDNS helps manage DNS across different cloud platforms, ensuring consistent access to services regardless of the underlying infrastructure.
Blue-Green Deployments: When performing blue-green or canary deployments, ExternalDNS can help dynamically switch DNS records as traffic is gradually routed to new versions of an application.
Private DNS Management: For internal DNS setups, ExternalDNS can manage private DNS records for services in a non-public namespace, ensuring services are accessible within a private network.

Conclusion

In this article, we explored various aspects of Kubernetes, including services, networking fundamentals, StatefulSets, and different types of services like NodePort, LoadBalancer, ExternalName, Ingress, and ExternalDNS. We delved into the specifics of how each service type functions, their use cases, and provided practical examples to illustrate their implementation. Understanding these components is crucial for effectively managing and deploying applications in a Kubernetes environment. By mastering these concepts, you can ensure your applications are scalable, resilient, and efficiently managed within your Kubernetes clusters.

💡 Let’s connect and discuss DevOps, cloud automation, and cutting-edge technology

🔗 LinkedIn | 💼 Upwork | 🐦 Twitter | 👨‍💻 GitHub

Kubernetes-part-8

Understanding Kubernetes Services: A Comprehensive Guide

What Are Endpoints in Kubernetes?

Exploring Different Types of Kubernetes Services

Networking Fundamentals in Kubernetes: A Deep Dive

StatefulSet: Managing Stateful Applications in Kubernetes

Key Differences Between Deployments and StatefulSets

NodePort: Exposing Your Kubernetes Application

Where it's useful ?

Create a Pod and expose it using NodePort service

LoadBalancer: Making Your Application Public

How It Works:

Why Avoid LoadBalancer in Production?

Alternatives to LoadBalancer for Kubernetes

ExternalName: Mapping Services to External DNS Names

Ingress: Controlling User Access to Kubernetes Applications

Why Use Ingress?

Example

ExternalDNS: Connecting Kubernetes to DNS Providers

How ExternalDNS Works

Use Cases for ExternalDNS

Conclusion

Kubernetes

Kubernetes-part-7

More from this blog

Hosting GitLab on Your Private Server with CI/CD: A How-To Guide

Capstone DevOps Project: Enterprise-Grade CI/CD Pipeline with Kubernetes on AWS, Jenkins, Helm, Ingress, and Monitoring

Ultimate Corporate-Grade DevSecOps Pipeline: Automated Kubernetes Deployment with Security, CI/CD, and Monitoring on AWS

Ultimate DevSecOps Project: End-to-End Kubernetes Three-Tier Deployment on AWS EKS with ArgoCD, Prometheus, Grafana & Jenkins

Deploying an Application on AWS EKS with Ingress: A Step-by-Step Guide

Command Palette

Understanding Kubernetes Services: A Comprehensive Guide

What Are Endpoints in Kubernetes?

Exploring Different Types of Kubernetes Services

Networking Fundamentals in Kubernetes: A Deep Dive

StatefulSet: Managing Stateful Applications in Kubernetes

Key Differences Between Deployments and StatefulSets

NodePort: Exposing Your Kubernetes Application

Where it's useful ?

Create a Pod and expose it using NodePort service

LoadBalancer: Making Your Application Public

How It Works:

Why Avoid LoadBalancer in Production?

Alternatives to LoadBalancer for Kubernetes

ExternalName: Mapping Services to External DNS Names

Ingress: Controlling User Access to Kubernetes Applications

Why Use Ingress?

Example

ExternalDNS: Connecting Kubernetes to DNS Providers

How ExternalDNS Works

Use Cases for ExternalDNS

Conclusion

Kubernetes

Kubernetes-part-7

More from this blog
